Guardrails are LangWatch evaluators attached to a virtual key. The gateway invokes them inline on every request and (optionally) every response, with three direction modes: pre (before dispatch), post (after a completed response), and stream_chunk (on every SSE chunk before emission). Evaluators are the same ones you already use for online evaluations in LangWatch — no new authoring surface. PII detection, prompt injection, toxicity, hallucination, regex guards, custom code evaluators — every type you have attached to a project is selectable as a gateway guardrail.

​
Direction modes

​
pre — block/modify the outgoing request

Invoked before the gateway dispatches to the upstream provider. Decisions:
  • allow — dispatch as-is.
  • block — return 403 guardrail_blocked to the client immediately. No upstream call is made. No spend.
  • modify — the evaluator returns a rewritten request payload (e.g. with PII redacted). The gateway dispatches the rewritten payload.
Use cases: prompt-injection detection, PII redaction before data hits a third-party provider, regex-based policy enforcement (“no customer emails in prompts”).

​
post — flag/block the response

Invoked on the full completed response for non-streaming calls, and on the reassembled stream for streaming calls. Wired on both /v1/chat/completions and /v1/messages. Decisions:
  • allow — response delivered to client.
  • block — for non-streaming, the response is replaced with 403 guardrail_blocked before the client sees the assistant text, and a zero-cost blocked_by_guardrail budget debit is recorded so dashboards still see the attempt (cost = $0, the provider call was made and paid for, but the ledger marks it as non-billable to the principal). For streaming, the response has already been delivered; the decision becomes a flag-only (propagated via the evaluator’s own trace span, not a dedicated gateway attribute in v1).
  • modify — the assistant text is rewritten in place (first choice content on /v1/chat/completions, first text block on /v1/messages); redaction is transparent from the client’s perspective. Streaming responses: flag-only.
Content-block responses skip post-evaluation. When the model returns a tool-call response (tool_calls on OpenAI, content: [{type: "tool_use", ...}] on Anthropic) or an image/file block, there’s no assistant text to evaluate — the post-guardrail is skipped rather than attempting to reason about structured output. Use pre on the tool-call arguments or a dedicated content-aware guardrail if you need to gate tool calls.
Use cases: hallucination detection on RAG outputs, PII leakage detection in responses, response-quality spot-checks.

​
Fail-open vs fail-closed

By default, post-guardrails fail closed: if the evaluator service is unavailable or errors, the response is replaced with 503 guardrail_upstream_unavailable — the user never sees an ungoverned response. For VKs where an unavailable guardrail should not block (e.g. best-effort redaction on low-stakes traffic), set guardrails.response_fail_open: true on the VK config. The gateway then passes the response through with a warning log. (No dedicated fail_open span attribute is emitted in v1; the response’s error class plus the guardrail upstream’s own span is how operators trace this path today.) pre guardrails use the same fail-closed default and the same VK opt-out (guardrails.request_fail_open).

​
stream_chunk — terminate per-chunk on visible deltas

Invoked on each SSE chunk with visible delta text before the gateway emits it to the client. Chunks without text — role-only frames ({"delta":{"role":"assistant"}}), tool-call frames, terminal usage frames — skip the guardrail call entirely. In practice this keeps ~95% of stream frames at pass-through cost. Decisions:
  • allow — emit chunk.
  • block — terminate the stream with a terminal event: error:
    event: error
data: {"error":{"type":"guardrail_blocked","code":"stream_chunk_blocked","message":"<reason>"}}
    The channel is closed immediately after; subsequent upstream chunks are discarded. Same wire shape as a provider-failure terminator, distinguishable by error.code (stream_chunk_blocked vs provider_error). See Streaming → Mid-stream error shapes.
  • modify — not implemented in v1. Chunk-level content rewriting is provider-shape-specific (OpenAI delta JSON vs Anthropic SSE events have different shapes). For v1, “redact on stream” = block and let the client retry without the offending input. A future iter may add provider-aware chunk rewriting once a real customer asks.
Latency budget: ≤50 ms per chunk. If the evaluator doesn’t respond in time, or the upstream guardrail errors, the gateway fails open — the chunk passes through with an OTel warning (the WARN log carries the reason) and a bump to gateway_guardrail_verdicts_total{direction="stream_chunk",verdict="fail_open"}. This is an explicit contract decision: blocking the user’s stream on a slow policy service is worse than occasional pass-through — but the metric makes slow/flaky services visible before they become reliability problems. Use cases: real-time PII termination (credit card numbers, emails, phone numbers) where the correct behaviour on detection is “stop sending and the user retries.” For best-effort redaction that doesn’t interrupt the stream, use post on the reassembled response instead.

​
Attaching guardrails to a VK

The VK create/edit drawer has three direction sections — Pre-request, Post-response, Stream chunk — each listing every project evaluator whose executionMode = AS_GUARDRAIL. Check the box next to an evaluator to attach it to that direction; uncheck to detach. Save the drawer — the gateway picks up the change within 30 s via the /changes long-poll. Each direction section also has a Default-block on evaluator failure toggle. Off (default) = fail closed (matches guardrails.request_fail_open: false / response_fail_open: false). On = fail open; the gateway WARN-logs the evaluator failure and proceeds. The helper copy cites the concrete enforcement shapes so you know what the toggle actually does:
  • Pre: blocks return 403 guardrail_blocked with a zero-cost debit.
  • Post: non-stream blocks replace the response with 403; stream responses flag only (the bytes are already out).
  • Stream chunk: blocks emit a byte-locked terminal SSE error with code=stream_chunk_blocked; the 50 ms per-chunk budget fails OPEN by contract regardless of the toggle (stream-chunk fail-open is a performance invariant, not a policy choice).
If the evaluator list is empty, the drawer points you at Evaluations → New to author one with Execution mode = As guardrail. That’s the same evaluator-authoring surface you already use for online evaluations; there’s no separate gateway-evaluator editor. Legacy surface — REST or CLI — still works for scripting:
# Attach a post-response guardrail via CLI (same operation as ticking the box)
langwatch virtual-keys update vk_01HZX... \
  --guardrail-add post:eval_pii_detector_v2

# Or via REST — full VK config PATCH
curl -X PATCH https://app.langwatch.ai/api/gateway/v1/virtual-keys/vk_01HZX... \
  -H "Authorization: Bearer $LANGWATCH_API_KEY" \
  -d '{"config":{"guardrails":{"post":[{"id":"eval_pii_detector_v2","evaluator":"pii_detection"}],"response_fail_open":false}}}'
Both the drawer and the REST/CLI emit the same {id, evaluator} tuple shape into the bundle (contract §4.2), so you can flip between surfaces without resetting configuration. A VK can have multiple guardrails in each direction; the gateway runs them in parallel and short-circuits on the first block decision.

​
Running them in parallel

The gateway fans out guardrail calls in parallel (bounded by MAX_GUARDRAIL_CONCURRENCY, default 8 per direction). First block wins — other in-flight guardrails are cancelled to save cost. modify decisions are applied in dependency order (a guardrail’s output is input to the next).

​
Observability

Prometheus counter gateway_guardrail_verdicts_total{direction, verdict} records every verdict the guardrail pipeline returns. Labels:
  • direction — request | response | stream_chunk
  • verdict — allow | block | modify | fail_open
v1 wiring caveat: in the Go data plane, only the stream_chunk direction currently emits this metric from the dispatcher hot path. The request and response directions run the guardrails correctly (block / modify logic works), but the dispatcher doesn’t yet call Metrics.RecordGuardrailVerdict at those sites. Tracked as a v1 follow-up (finding #17); operators who need per-direction allow-rate dashboards today can proxy from gateway_http_requests_total{status="403"} which flips on every block verdict regardless of direction.
Span attributes: the gateway declares langwatch.guardrail.verdict as a canonical span attribute for the aggregate verdict, but it is not yet emitted from the dispatcher in v1. Per-guardrail decision detail is visible by clicking through to the evaluator’s run in the LangWatch Messages view — the evaluator’s own trace carries the policies triggered + reasoning.

​
Permissions

  • gatewayGuardrails:attach — attach a guardrail to a VK.
  • gatewayGuardrails:detach — remove one.
  • Evaluator CRUD uses the existing evaluations:* permissions (unchanged).

​
Cost

Every guardrail call is a separate LangWatch evaluator run. It’s metered against your LangWatch plan the same as any other online-evaluation run.

​
Blocking vs modifying — when to pick which

  • Block when the request/response is unfixable and the only correct behaviour is to fail fast. Example: prompt-injection detected in a user query — never forward.
  • Modify when there’s a safe redacted version the user should still see. Example: PII in input → redact with [REDACTED] markers and forward the rest.
  • Stream_chunk modify when real-time is essential. Example: the model is emitting a credit-card number mid-stream; redact before the user sees it.
Start with allow + flag (just log without blocking) while tuning a guardrail’s thresholds. Promote to block or modify once the false-positive rate is low.

​
Further reading

  • Policy Rules for simpler regex-based denials (tools, MCPs, URLs, models) that don’t need an evaluator.
  • Streaming for the full SSE contract.
